PVC profile systems
S series
S series STEKO windows are made from a profile for those who values the quality-price ratio. This profile is similar to the European analogues because it has excellent operating characteristics, good indicators of the thermal transmittance and sophisticated design.
Steko IDEAL series
German profile Steko IDEAL series by Aluplast corresponds to all the European norms and quality standards. It`s developed for those who values comfort, reliability and style.
Ukrainian profile Steko S300
Number of chambers: | 3 |
Profile width: | 58 mm |
Frame height: | 61,5 mm |
Glass width: | 4, 6, 24, 30 mm |
Outer wall thickness: | 2,6 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Thermal transmittance: | R=0.63 m2К/Wt |
Reinforcing profile: | |
Color palette: |
Steko S500
Number of chambers: | 5 |
Profile width: | 60 mm |
Frame height: | 62 mm |
Glass width: | 24, 30 mm |
Outer wall thickness: | 2,6 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Thermal transmittance: | U=1.3 W/m2K |
Reinforcing profile: | |
Color palette: |
European profile Steko R500
Number of chambers: | 5 |
Number of sash chambers: | 5 |
Profile width: | 70 mm |
language.Sash width | 70 mm |
Frame height: | 66 mm |
Glass width: | 24, 30, 36 mm |
Outer wall thickness: | 2,7 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Thermal transmittance: | U=1.3 W/m2K |
Reinforcing profile: | |
Color palette: |
European profile Steko R600
Number of chambers: | 5 |
Number of sash chambers: | 6 |
Profile width: | 70 mm |
language.Sash width | 80 mm |
Frame height: | 66 mm |
Glass width: | 24, 30, 36 mm |
Outer wall thickness: | 2,7 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Thermal transmittance: | U=1.3 W/m2K |
Reinforcing profile: | |
Color palette: |
European profile Steko Reiner R 700
Number of chambers: | 7 |
Profile width: | 82 mm |
Frame height: | 44 mm |
Glass width: | 44 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | IV |
Thermal transmittance: | Uf=1.1 W/m2K |
European profile Steko R600
Number of chambers: | 5 |
Number of sash chambers: | 6 |
Profile width: | 70 mm |
language.Sash width | 80 mm |
Frame height: | 66 mm |
Glass width: | 24, 30, 36 mm |
Outer wall thickness: | 2,7 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Thermal transmittance: | R=0.82 m2К/Wt |
Reinforcing profile: | |
Color palette: |
German profile Steko IDEAL 4000
Number of chambers: | 6 |
Profile width: | 70 mm |
Frame height: | 65 mm |
Glass width: | 40 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Thermal transmittance: | Uf=1.2 W/m2К |
Anti-theft class | RC2 |
German profile Steko IDEAL 7000
Number of chambers: | 6 |
Profile width: | 85 mm |
Frame height: | 70 mm |
Outer wall thickness: | 2.7 mm |
Glass width: | 44 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Anti-theft class | RC2 |
Thermal transmittance: | Uf=1.1 W/m2К |
German profile Steko IDEAL 8000 Round Line
Number of chambers: | 6 |
Profile width: | 85 mm |
Frame height: | 80 mm |
Glass width: | 44 mm |
Seal contours: | 3 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Anti-theft class | RC3 |
Thermal transmittance: | Uf=1.0 W/m2К |
European profile Steko V90
Number of chambers: | 6 |
Profile width: | 90 mm |
Frame height: | 84 mm |
Glass width: | 44 mm |
Soundproofing | RC3 |
Thermal transmittance: | R=1.0 м2К/Вт |
Color palette: |
European profile Steko S700
Number of chambers: | 7 |
Profile width: | 70 mm |
Frame height: | 65 mm |
Glass width: | 24, 32, 40 mm |
Soundproofing | VDI 2719 |
Noise insulation class: | II to IV |
Thermal transmittance: | Uf=1.2 W/m2K |
Color palette: |
